PII Masking - Presidio

Quick Start​

LiteLLM supports Microsoft Presidio for PII masking.

1. Define Guardrails on your LiteLLM config.yaml​

Define your guardrails under the guardrails section

model_list:
  - model_name: gpt-3.5-turbo
    litellm_params:
      model: openai/gpt-3.5-turbo
      api_key: os.environ/OPENAI_API_KEY

guardrails:
  - guardrail_name: "presidio-pre-guard"
    litellm_params:
      guardrail: presidio  # supported values: "aporia", "bedrock", "lakera", "presidio"
      mode: "pre_call"

Set the following env vars

export PRESIDIO_ANALYZER_API_BASE="http://localhost:5002"
export PRESIDIO_ANONYMIZER_API_BASE="http://localhost:5001"

Supported values for mode​

  • pre_call Run before LLM call, on input
  • post_call Run after LLM call, on input & output
  • logging_only Run after LLM call, only apply PII Masking before logging to Langfuse, etc. Not on the actual llm api request / response.

2. Start LiteLLM Gateway​

litellm --config config.yaml --detailed_debug

3. Test request​

Langchain, OpenAI SDK Usage Examples

Expect this to mask Jane Doe since it's PII

curl http://localhost:4000/chat/completions \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer sk-1234" \
  -d '{
    "model": "gpt-3.5-turbo",
    "messages": [
      {"role": "user", "content": "Hello my name is Jane Doe"}
    ],
    "guardrails": ["presidio-pre-guard"],
  }'

Expected response on failure

{
 "id": "chatcmpl-A3qSC39K7imjGbZ8xCDacGJZBoTJQ",
 "choices": [
   {
     "finish_reason": "stop",
     "index": 0,
     "message": {
       "content": "Hello, <PERSON>! How can I assist you today?",
       "role": "assistant",
       "tool_calls": null,
       "function_call": null
     }
   }
 ],
 "created": 1725479980,
 "model": "gpt-3.5-turbo-2024-07-18",
 "object": "chat.completion",
 "system_fingerprint": "fp_5bd87c427a",
 "usage": {
   "completion_tokens": 13,
   "prompt_tokens": 14,
   "total_tokens": 27
 },
 "service_tier": null
}

Advanced​

Set language per request​

The Presidio API supports passing the language param. Here is how to set the language per request

curl http://localhost:4000/chat/completions \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer sk-1234" \
  -d '{
    "model": "gpt-3.5-turbo",
    "messages": [
      {"role": "user", "content": "is this credit card number 9283833 correct?"}
    ],
    "guardrails": ["presidio-pre-guard"],
    "guardrail_config": {"language": "es"}
  }'

Output parsing​

LLM responses can sometimes contain the masked tokens.

For presidio 'replace' operations, LiteLLM can check the LLM response and replace the masked token with the user-submitted values.

Define your guardrails under the guardrails section

model_list:
  - model_name: gpt-3.5-turbo
    litellm_params:
      model: openai/gpt-3.5-turbo
      api_key: os.environ/OPENAI_API_KEY

guardrails:
  - guardrail_name: "presidio-pre-guard"
    litellm_params:
      guardrail: presidio  # supported values: "aporia", "bedrock", "lakera", "presidio"
      mode: "pre_call"
      output_parse_pii: True

Expected Flow:

  1. User Input: "hello world, my name is Jane Doe. My number is: 034453334"

  2. LLM Input: "hello world, my name is [PERSON]. My number is: [PHONE_NUMBER]"

  3. LLM Response: "Hey [PERSON], nice to meet you!"

  4. User Response: "Hey Jane Doe, nice to meet you!"

Ad Hoc Recognizers​

Send ad-hoc recognizers to presidio /analyze by passing a json file to the proxy

Example ad-hoc recognizer

Define ad-hoc recognizer on your LiteLLM config.yaml​

Define your guardrails under the guardrails section

model_list:
  - model_name: gpt-3.5-turbo
    litellm_params:
      model: openai/gpt-3.5-turbo
      api_key: os.environ/OPENAI_API_KEY

guardrails:
  - guardrail_name: "presidio-pre-guard"
    litellm_params:
      guardrail: presidio  # supported values: "aporia", "bedrock", "lakera", "presidio"
      mode: "pre_call"
      presidio_ad_hoc_recognizers: "./hooks/example_presidio_ad_hoc_recognizer.json"

Set the following env vars

export PRESIDIO_ANALYZER_API_BASE="http://localhost:5002"
export PRESIDIO_ANONYMIZER_API_BASE="http://localhost:5001"

You can see this working, when you run the proxy:

litellm --config /path/to/config.yaml --debug

Make a chat completions request, example:

{
  "model": "azure-gpt-3.5",
  "messages": [{"role": "user", "content": "John Smith AHV number is 756.3026.0705.92. Zip code: 1334023"}]
}

And search for any log starting with Presidio PII Masking, example:

Presidio PII Masking: Redacted pii message: <PERSON> AHV number is <AHV_NUMBER>. Zip code: <US_DRIVER_LICENSE>

Logging Only​

Only apply PII Masking before logging to Langfuse, etc.

Not on the actual llm api request / response.

note

This is currently only applied for

  • /chat/completion requests
  • on 'success' logging
  1. Define mode: logging_only on your LiteLLM config.yaml

Define your guardrails under the guardrails section

model_list:
  - model_name: gpt-3.5-turbo
    litellm_params:
      model: openai/gpt-3.5-turbo
      api_key: os.environ/OPENAI_API_KEY

guardrails:
  - guardrail_name: "presidio-pre-guard"
    litellm_params:
      guardrail: presidio  # supported values: "aporia", "bedrock", "lakera", "presidio"
      mode: "logging_only"

Set the following env vars

export PRESIDIO_ANALYZER_API_BASE="http://localhost:5002"
export PRESIDIO_ANONYMIZER_API_BASE="http://localhost:5001"
  1. Start proxy
litellm --config /path/to/config.yaml
  1. Test it!
curl -X POST 'http://0.0.0.0:4000/chat/completions' \
-H 'Content-Type: application/json' \
-H 'Authorization: Bearer sk-1234' \
-D '{
  "model": "gpt-3.5-turbo",
  "messages": [
    {
      "role": "user",
      "content": "Hi, my name is Jane!"
    }
  ]
  }'

Expected Logged Response

Hi, my name is <PERSON>!
