Cut 69% Costs Stacking Auto-Routing on Prompt Caching

Yes, you can use prompt caching with Auto-Routing. The two compound rather than cancel out. We measured it across five datasets, two of which report what the provider's cache actually did.

🚀 Help shape the Auto-Router

Get early access, work directly with the LiteLLM team, and influence the roadmap with your production traffic.

Apply to Become a Design Partner

Already testing it? Share your results in discussion #32168.

The results

• Auto-routing does not break prompt caching. The two compound on every dataset we measured
• 37% to 69% cheaper than caching alone on a single model
• The real failure mode is the opposite one. Running a router with caching switched off is about 4x more expensive than caching one fixed model

Evaluation	Sample	Router + caching, vs caching alone
Simulation, general chat (WildChat-1M)	30,769 multi-turn conversations	68.7% cheaper
Simulation, developer chat (DevGPT)	1,011 conversations	46% cheaper
Real agent traces, provider cache accounting	95 sessions, 8,174 API calls	37.4% cheaper
TwinRouterBench static track	81 multi-step instances	44 to 50% cheaper

How it was measured

• Router arm: one model group, four tiers. SIMPLE to claude-haiku-4-5, MEDIUM to claude-sonnet-5, COMPLEX and REASONING to claude-opus-5
• Baseline arm: every request to one frontier model with prompt caching on, the strongest realistic baseline rather than a cold-priced strawman
• Cache behaviour: read from usage.cache_read_input_tokens and cache_creation_input_tokens on the gateway spend logs and agent traces; modelled on the other three legs
• Turn classification: one window function partitioned by session and model, labelling each turn as staying on a model, first visiting a tier, or returning to one already used

Why auto-routing doesn't break prompt caching

99.3% of the time a session switches back to a model it used earlier, that model's cache is still warm. The router comes back long before the cache expires, so a switch is not an eviction.

We measured this on 4,684 real switch-backs from live LiteLLM gateway traffic.

Provider cache state	% of Model Returns with Warm Cache
Still warm at 5m TTL	97.4%
Still warm at 1h TTL	99.3%
Past TTL, the only ones a switch could have hurt	2.6% / 0.7%

We tried a background cache warmer. It wasn't worth it

If switching really did strand the cache, a background refresher that replays a session's prefix would be the fix. We built the measurement for it first.

Only 4% of cache misses are preventable by a background cache warmer. The rest either happened while the cache was still alive, or after the model had been idle so long that keeping it warm costs more than the write it avoids.

Traffic	Typical prefix	What warming does to total cost
General chat	~1,700 tokens	0.10% more expensive
Agent traces, multi-hour gaps	large	0.63% more expensive
Our gateway, agentic	~190,000 tokens	0.9% cheaper

Warming is worth roughly plus or minus two percent: a narrow optimization for long sessions with large stable prefixes, not the thing standing between a deployment and its savings.

See it on your own traffic

The Auto-Router Benchmarks tab now reports prompt cache behaviour per router, from the provider's own usage payload:

• Hit rate, split by whether the turn stayed on a model, first visited a tier, or returned to one
• Expired-miss share, narrowing return misses to those whose tier went idle past the TTL
• Savable by warming, the share of all misses a refresher could prevent
• Warming cost and net estimate, in dollars
• Coverage, so a low hit rate caused by response logging being off does not read as a cold cache

GET /auto_router/benchmarks?start_date=2026-07-01&end_date=2026-07-31

Try it

info

Point a client at an auto-router with prompt caching on, then check the Auto-Router Benchmarks tab against your own traffic. Share numbers or questions on discussion #32168. To work on this with us directly, apply to be a design partner.

config.yaml

model_list:
  - model_name: claude-haiku-4-5
    litellm_params:
      model: anthropic/claude-haiku-4-5
      api_key: os.environ/ANTHROPIC_API_KEY
  - model_name: claude-sonnet-5
    litellm_params:
      model: anthropic/claude-sonnet-5
      api_key: os.environ/ANTHROPIC_API_KEY
  - model_name: claude-opus-5
    litellm_params:
      model: anthropic/claude-opus-5
      api_key: os.environ/ANTHROPIC_API_KEY

  - model_name: smart-router
    litellm_params:
      model: auto_router/complexity_router
      complexity_router_config:
        tiers:
          SIMPLE:    claude-haiku-4-5
          MEDIUM:    claude-sonnet-5
          COMPLEX:   claude-opus-5
          REASONING: claude-opus-5
        classifier_type: heuristic
      complexity_router_default_model: claude-sonnet-5

Every response carries x-litellm-model-name and x-litellm-response-cost, and the provider's cache token counts land in the spend logs. Full reference on the Auto Routing docs page.
